Product Overview

Seamless band type aluminium suspended luminaire for indoor architectural lighting solution excellent energy saving operation featured with best-in-class LED light sources with high luminous efficacy and highly translucence optical system to ensure maximum light output with excellent glare control and uniformity.

Best suited for

Reception & public service areas

Waiting Lounge

Meeting Rooms

Food courts

View full details
  • General specification
    Housing Designed with excellent thermally managed aluminium housing with heat dissipating larger surface area.
    Optics High quality polycarbonate opal diffuser for glare free uniform light distribution.
    Mounting Pendant mounting
    Control Gear Powered by an integral electronic LED driver (SMPS based constant current supply) with Output Short circuit protection, Surge protection & other reliability tests.
    Surge Protection Upto 2.5 KV
    IP 20
  • Technical Specifications
    System Wattage 30W, 45W, 60W, 80W, 90W, 120W, 180W
    CCT 5700K , 4000K , 3000K
    CRI ≥80
    Rated Voltage 240V AC
    Power Factor ≥0.95
    THD <20%
    System Efficacy (Im/w) ≥100, ≥90, ≥85
BDline variants
Product Variants
BDline
LCPBDL30-30-C-50
BDline
LCPBDL30-30-N-50
BDline
LCPBDL30-30-W-50
BDline
LCPBDL45-45-C-50
BDline
LCPBDL45-45-N-50
BDline
LCPBDL45-45-W-50
BDline
LCPBDL60-60-C-50
BDline
LCPBDL60-60-N-50
BDline
LCPBDL60-60-W-50
BDline
LCPBDL80-80-C-50
BDline
LCPBDL80-80-N-50
BDline
LCPBDL80-80-W-50
BDline
LCPBDL90-90-C-50
BDline
LCPBDL90-90-N-50
BDline
LCPBDL90-90-W-50
BDline
LCPBDL120-120-C50
BDline
LCPBDL120-120-N50
BDline
LCPBDL120-120-W50
BDline
LCPBDL180-180-C50
BDline
LCPBDL180-180-N50
BDline
LCPBDL180-180-W50
System Wattage
CCT
CRI
Rated Voltage
Power Factor
THD
System Efficacy (Im/w)
Length (in mm)
Width (in mm)
Height (in mm)
30W
5700K
≥80
240V AC
≥0.95
<20%
≥100
300
50
75
30W
4000K
≥80
240V AC
≥0.95
<20%
≥90
300
50
75
30W
3000K
≥80
240V AC
≥0.95
<20%
≥85
300
50
75
45W
5700K
≥80
240V AC
≥0.95
<20%
≥100
450
50
75
45W
4000K
≥80
240V AC
≥0.95
<20%
≥90
450
50
75
45W
3000K
≥80
240V AC
≥0.95
<20%
≥85
450
50
75
60W
5700K
≥80
240V AC
≥0.95
<20%
≥100
600
50
75
60W
4000K
≥80
240V AC
≥0.95
<20%
≥90
600
50
75
60W
3000K
≥80
240V AC
≥0.95
<20%
≥85
600
50
75
80W
5700K
≥80
240V AC
≥0.95
<20%
≥100
800
50
75
80W
4000K
≥80
240V AC
≥0.95
<20%
≥90
800
50
75
80W
3000K
≥80
240V AC
≥0.95
<20%
≥85
800
50
75
90W
5700K
≥80
240V AC
≥0.95
<20%
≥100
900
50
75
90W
4000K
≥80
240V AC
≥0.95
<20%
≥90
900
50
75
90W
3000K
≥80
240V AC
≥0.95
<20%
≥85
900
50
75
120W
5700K
≥80
240V AC
≥0.95
<20%
≥100
1200
50
75
120W
4000K
≥80
240V AC
≥0.95
<20%
≥90
1200
50
75
120W
3000K
≥80
240V AC
≥0.95
<20%
≥85
1200
50
75
180W
5700K
≥80
240V AC
≥0.95
<20%
≥100
1800
50
75
180W
4000K
≥80
240V AC
≥0.95
<20%
≥90
1800
50
75
180W
3000K
≥80
240V AC
≥0.95
<20%
≥85
1800
50
75
