Product Overview

Industrial bulkhead luminaire designed with PC housing and heat-resistant polycarbonate diffuser.

View full details
  • General specification
    Housing Excellent thermally managed polycarbonate housing
    Optics Opal polycarbonate diffuser for glare free symmetric light.
    Mounting Surface mounting by mounting clips
    Control Gear Powered by an integral electronic LED driver (SMPS based constant current supply) with Output Short circuit protection, Surge protection & other reliability tests.
    Surge Protection Upto 2.5 KV
    IP 65
  • Technical Specifications
    System Wattage 10W
    CCT 6500K | 3000K
    CRI ≥70
    Rated Voltage 240V AC
    Power Factor ≥0.95
    THD ≤15%
    System efficacy (lm/W)|≥85 , ≥70 System efficacy (lm/W)|≥85 , ≥70
Bulkhead PC variants
Product Variants
Bulkhead PC
LIBH-10-C-P
Bulkhead PC
LIBH-10-W-P
System Wattage
CCT
CRI
Rated Voltage
Power Factor
TDH
System efficacy (lm/W)
Length (in mm)
Width (in mm)
Height (in mm)
10W
6500K
≥70
240V AC
≥0.95
≤15%
≥85
203
110
46
10W
3000K
≥70
240V AC
≥0.95
≤15%
≥70
203
110
46
