Dazzler

Dazzler

Dazzler

Product Overview

Recess-mounting deep recess round LED downlighter designed with excellent thermally managed PC housing with heat-dissipating fins for larger surface area.

Best suited for

Banking

Offices

Reception

Waiting Lounge

Meeting Rooms

Corridors

View full details
  • General specification
    Housing Designed with excellent thermally managed polycarbonate housing with heat dissipating larger surface area.
    Optics High quality polycarbonate frosted diffuser for glare free uniform light distribution.
    Mounting Fixing into false ceiling by means of spring & clips provided
    Control Gear Powered by an independent electronic LED driver (SMPS based constant current supply) with Output Short circuit protection,Surge protection & other reliability tests
    Surge Protection Upto 2.5 KV
    IP 20
  • Technical Specifications
    System Wattage 5W, 10W, 15W
    CCT 6500K , 4000K , 3000K
    CRI ≥80
    Rated Voltage 240V AC
    Power Factor ≥0.95
    THD <20%
    System Efficacy (lm/W) ≥100 , ≥90 , ≥80
Dazzler variants
Product Variants
Dazzler
LDRDZ-05-C
Dazzler
LDRDZ-05-N
Dazzler
LDRDZ-05-W
Dazzler
LDRDZ-10-C
Dazzler
LDRDZ-10-N
Dazzler
LDRDZ-10-W
Dazzler
LDRDZ-15-C
Dazzler
LDRDZ-15-N
Dazzler
LDRDZ-15-W
System Wattage
CCT
CRI
Rated Voltage
Power Factor
THD
System Efficacy (lm/W)
Outer Diameter (in mm)
Cut Out Diameter (in mm)
Height (in mm)
5W
6500K
≥80
240V AC
≥0.95
<20%
≥100
79
68
49
5W
4000K
≥80
240V AC
≥0.95
<20%
≥90
79
68
49
5W
3000K
≥80
240V AC
≥0.95
<20%
≥80
79
68
49
10W
6500K
≥80
240V AC
≥0.95
<20%
≥100
119
110
56
10W
4000K
≥80
240V AC
≥0.95
<20%
≥90
119
110
56
10W
3000K
≥80
240V AC
≥0.95
<20%
≥80
119
110
56
15W
6500K
≥80
240V AC
≥0.95
<20%
≥100
152
143
61
15W
4000K
≥80
240V AC
≥0.95
<20%
≥90
152
143
61
15W
3000K
≥80
240V AC
≥0.95
<20%
≥80
152
143
61
