Dline Recess Tunable

Dline Recess Tunable

Dline Recess Tunable

Product Overview

Recess LED linear light in aluminium housing with Human-centric property provides improved productivity, better moods and overall healthier workspaces. Tunable with optional pre-set colour temperatures or manual adjustments to any CCT in the range 3000K-6500K along with lux sensing & dimming possibilities. Wired and wireless communication mode available as per site mapping. Mobile Application interface for easiness of operations.

View full details
  • General specification
    Housing Designed with excellent thermally managed aluminium housing with heat dissipating larger surface area.
    Optics High quality polycarbonate opal diffuser for glare-free uniform light distribution.
    Mounting Recess mounting
    Control Gear Powered by an integral electronic LED driver (SMPS based constant current supply) with Output Short-circuit protection,Surge protection & other reliability tests
    Surge Protection Upto 2.5 KV
    IP 20
  • Technical Specifications
    System Wattage 24W | 30W | 36W
    CCT 3000K-6500K
    CRI ≥80
    Rated Voltage 240V AC
    Power Factor ≥0.95
    THD <10%
    System efficacy (lm/W) ≥100
Dline Recess Tunable variants
Product Variants
Dline Recess Tunable
LCRDL4-24-HC-50
Dline Recess Tunable
LCRDL4-30-HC-50
Dline Recess Tunable
LCRDL4-36-HC-50
System Wattage
CCT
CRI
Rated Voltage
Power Factor
THD
System efficacy (lm/W)
Length (in mm)
Width (in mm)
Height (in mm)
Cutout (in mm)
24W
3000K-6500K
≥80
240V AC
≥0.95
<10%
≥100
1208
63
30
1196 x 52
30W
3000K-6500K
≥80
240V AC
≥0.95
<10%
≥100
1208
63
30
1196 x 52
36W
3000K-6500K
≥80
240V AC
≥0.95
<10%
≥100
1208
63
30
1196 x 52
