RAY-D (Dual CCT)

RAY-D (Dual CCT)

RAY-D (Dual CCT)

Product Overview

IP66 Dual CCT street lighting system based on DIY concept that enhances ambiance and safety for road illumination in cool white and warm white CCTs as per seasonal and functional demands.

Best suited for

Hilly regions roads

Mall roads

City plazas

Smart cities

View full details
  • General specification
    Housing Excellent thermally managed aluminium die cast housing.
    Optics PC diffuser with integrated Lens
    Mounting Bracket provided for mounting
    Control Gear Powered by an integral electronic LED driver (SMPS based constant current supply) with Output Short-circuit protection, Surge protection & other reliability tests.
    Surge Protection Upto 4 KV (optional 10 KV SPD)
    IP 66
  • Technical Specifications
    System Wattage 45W , 90W
    CCT 3000K & 5700K
    CRI ≥70
    Rated Voltage 240 V AC
    Power Factor ≥0.95
    THD ≤10%
    System efficacy (lm/W) ≥90, ≥100
RAY-D (Dual CCT) variants
Product Variants
RAY-D (Dual CCT)
LSRAD-045-WC-PC
RAY-D (Dual CCT)
LSRAD-090-WC-PC
System Wattage
CCT
CRI
Rated Voltage
Power Factor
THD
System efficacy (lm/W)
Length (in mm)
Width (in mm)
Height (in mm)
Pole OD (in mm)
45W
3000K & 5700K
≥70
240VAC
≥0.95
≤10%
≥90 , ≥100
302
102
60
39
90W
3000K & 5700K
≥70
240VAC
≥0.95
≤10%
≥90 , ≥100
323
187
97
55
