Product Overview

Track based spotlight with high efficiency reflector makes it ideal for lighting-up retail spaces with bright and crisp light.

View full details
  • General specification
    Housing Designed with excellent thermally managed aluminium housing finished in epoxy powder coated white.
    Optics Clear glass diffuser
    Mounting Track based
    Control Gear Powered by an integral electronic LED driver (SMPS based constant current supply) with Output Short circuit protection, Surge protection & other reliability tests.
    Surge Protection Upto 2.5 KV
    IP 20
  • Technical Specifications
    System Wattage 10W, 20W, 30W
    CCT 6500K | 4000K | 3000K
    CRI ≥80
    Rated Voltage 240V AC
    Power Factor ≥0.95
    THD <20%
    System efficacy (lm/W) ≥90, ≥85, ≥80
Track light variants
Product Variants
Track light
LTSTL-10-C-V1
Track light
LTSTL-10-N-V1
Track light
LTSTL-10-W-V1
Track light
LTSTL-20-C-V1
Track light
LTSTL-20-N-V1
Track light
LTSTL-20-W-V1
Track light
LTSTL-30-C-V1
Track light
LTSTL-30-N-V1
Track light
LTSTL-30-W-V1
System Wattage
CCT
CRI
Rated Voltage
Power Factor
THD
System Efficacy (lm/W)
Length (in mm)
Height (in mm)
10W
6500K
≥80
240V AC
≥0.95
<20%
≥90
60
100
10W
4000K
≥80
240V AC
≥0.95
<20%
≥90
60
100
10W
3000K
≥80
240V AC
≥0.95
<20%
≥90
60
100
20W
6500K
≥80
240V AC
≥0.95
<20%
≥90
88
130
20W
4000K
≥80
240V AC
≥0.95
<20%
≥90
88
130
20W
3000K
≥80
240V AC
≥0.95
<20%
≥90
88
130
30W
6500K
≥80
240V AC
≥0.95
<20%
≥90
88
145
30W
4000K
≥80
240V AC
≥0.95
<20%
≥90
88
145
30W
3000K
≥80
240V AC
≥0.95
<20%
≥90
88
145
