Product Overview

LED downlighter in surface mounting round shaped designed with excellent thermally managed aluminium pressure die-cast housing with larger surface area finished in epoxy powder-coated white.

View full details
  • General specification
    Housing Designed with excellent thermally managed aluminium housing with heat dissipating fins for larger surface area finished in epoxy powder coated white.
    Optics High quality polycarbonate frosted diffuser for glare free uniform light distribution.
    Mounting Surface mounting
    Control Gear Powered by an integral electronic LED driver (SMPS based constant current supply) with Output Short circuit protection, Surge protection & other reliability tests.
    Surge Protection Upto 2.5 KV
    IP 20
  • Technical Specifications
    System Wattage 10W, 15W, 20W, 24W
    CCT 6500K , 4000K , 3000K
    CRI ≥80
    Rated Voltage 240V AC
    Power Factor ≥0.95
    THD ≤15%
    System Efficacy (lm/W) ≥100 , ≥90 , ≥85
Venus surface variants
Product Variants
Venus surface
LDSVS-010-C-V0
Venus surface
LDSVS-010-N-V0
Venus surface
LDSVS-010-W-V0
Venus surface
LDSVS-015-C-V0
Venus surface
LDSVS-015-N-V0
Venus surface
LDSVS-015-W-V0
Venus surface
LDSVS-020-C-V0
Venus surface
LDSVS-020-N-V0
Venus surface
LDSVS-020-W-V0
Venus surface
LDSVS-024-C-V0
Venus surface
LDSVS-024-N-V0
Venus surface
LDSVS-024-W-V0
System Wattage
CCT
CRI
Rated Voltage
Power Factor
THD
System Efficacy (lm/W)
Outer Diameter (in mm)
Height (in mm)
10W
6500K
≥80
240V AC
≥0.95
≤15%
≥100
122
60
10W
4000K
≥80
240V AC
≥0.95
≤15%
≥90
122
60
10W
3000K
≥80
240V AC
≥0.95
≤15%
≥85
122
60
15W
6500K
≥80
240V AC
≥0.95
≤15%
≥100
147
60
15W
4000K
≥80
240V AC
≥0.95
≤15%
≥90
147
60
15W
3000K
≥80
240V AC
≥0.95
≤15%
≥85
147
60
20W
6500K
≥80
240V AC
≥0.95
≤15%
≥100
173
60
20W
4000K
≥80
240V AC
≥0.95
≤15%
≥90
173
60
20W
3000K
≥80
240V AC
≥0.95
≤15%
≥85
173
60
24W
6500K
≥80
240V AC
≥0.95
≤15%
≥100
173
60
24W
4000K
≥80
240V AC
≥0.95
≤15%
≥90
173
60
24W
3000K
≥80
240V AC
≥0.95
≤15%
≥85
173
60
