Product Overview

Ultrabright polycarbonate LED retrofit tube light with high efficacy of ≥120lm/W suitable for replacement of existing T8 & T12 fluorescent tube light with G13 lamp holder with double side connection.

View full details
  • General specification
    Housing Elegantly designed polycarbonate housing with opal finish to provide glare-free uniform light distribution. High quality polycarbonate end caps are snap - fitted to the housing.
    Optics Polycarbonate diffuser to provide glare - free uniform light distribution. High lumen efficacy LED with viewing angle of 120° used to enhance the lumen output.
    Mounting Directly installed in existing T8/T12 FTL conventional lighting fixtures.
    Control Gear Powered by an integral constant - current driver suitable for 120-280 V AC working range.
    Surge Protection Upto 2.5 KV
    IP 20
  • Technical Specifications
    System Wattage 18W
    CCT 6500K | 4000K | 3000K
    CRI ≥80
    Rated Voltage 240V AC
    Power Factor ≥0.95
    THD <15%
    System efficacy (lm/W) ≥120 , ≥110 , ≥105
XLINE XT variants
Product Variants
XLINE XT
LTXL-18-C-XT-DV1
XLINE XT
LTXL-18-N-XT-DV1
XLINE XT
LTXL-18-W-XT-DV1
System Wattage
CCT
CRI
Rated Voltage
Power Factor
THD
System efficacy (lm/W)
Length (in mm)
Height (in mm)
18W
6500K
≥80
240V AC
≥0.95
<15%
≥120
1212
28
18W
4000K
≥80
240V AC
≥0.95
<15%
≥110
1212
28
18W
3000K
≥80
240V AC
≥0.95
<15%
≥105
1212
28
